Classification: Male Header; pin header
0.200"(5.08mm)Pitch Pin header
Current Rating: 7.9 Amp
Insulation Resistance: 1000MΩ Min
Dielectric Withstanding: 1500V AC
Contact Resistance: 20mΩ Max
Operating Temperature: -40°C to +105°C
OEM/ODM： Accepted
5.08 Pitch Pin Header - Single Row H2.5 - DIP Type
Product Description
| Product Name | 0.200" 5.08mm Pitch Single Row Straight Pin Header |
| Pitch | 0.200" (5.08mm) Pitch |
| Material | PBT PA6T PA9T LCP |
| Pin Plating | Tin or gold over nickel |
| Package | Bag packing,Tube packing,Tape&Reel packing |
| OEM/ODM | Accept and made based on drawing or samples |
| Payment Terms | FOB,DDP,T/T,L/C,PayPal,Western Union |
| Lead time | 7-10 Days |
| Application | PCB board |
| Positions | 1~20Pin |
| Samples | Free |
| Insulator Flammability | UL94V-0 |
| Company Advantage | 1.Factory and trade integration,18 years export experience; 2.One-stop shopping; 3.Competitive price; 5.Timely delivery; 6.Technical support; 7.Samples for free; |
